Products
Racking Systems
The Industry Standard for cask racking is currently manual lift or lifter/lift truck. These systems are typically supplied the same – a rack is supplied with stillages and the option of a purchasing a lifter is provided
Lifters are seriously limited in practical use. They require a lot of space to work, the floor to be even and clear of beer lines.
While they do not require the operator to physically lift the cask their use does demand a lot of physical effort and manipulation to load the cask. The result often, particularly where 9 gallon casks are used, is to ignore the lifter and manually load the rack.
Loading a standard rack without a lifter requires the cask to be manipulated under and over the rack
CELLAR HANDLING’S approach is simple.
If a rack is to be loaded manually, design it so it can be loaded with minimum effort.
If mechanical support is required, make it purposeful
Floor Stillages
Mini Tilt – 9 Gallon Tilting Stillage
The Mini Tilt will achieve yields typical of tilting stillages, ie < 2 pints wastage
It is fabricated in mild steel and coated in nylon plastic which is impervious to beer and cleaning fluids.
The feet are adjustable to accommodate uneven floors
Loading the stillage is easily achieved levering the cask onto the stillage with the front forks
Auto Tilt – 9 / 18 Gallon Casks
The Auto Tilt will achieve yields typical of tilting stillages, ie < 2 pints wastage. The stillage is supplied with 2 easy to change springs – silver for 9 gallon and gold for 18
It is fabricated in mild steel and coated in nylon plastic which is impervious to beer and cleaning fluids.
The feet are adjustable to accommodate uneven floors
Loading the stillage is easily achieved levering the cask onto the stillage with the front forks. The cradle is fit with 4 wheels enabling the keystone to be positioned when it has loaded
Check our Products page for images
Mobile Bar
Cellar Handling’s portable bars are designed to enable easy transportation and setup
The bars are fabricated from light weight mild steel and powder coated
The bars are supplied in 3 sections – the main body which folds up on fixed hinges, an easy to fit shelf and a worktop which is tower bolted to the frame
The frame has U channels fit to the top and bottom of the front and side sections enabling advertising/promotion panels to be slide in
The standard dimensions are 1130mm high 1220mm long and 600mm deep. Individual requirements can of course be accommodated
